| Model | POW-M60-PRO |
| Charging mode | MPPT Maximum power point tracking automatically |
| Charging | 3-stage:constant current(MPPT), constant voltage(Absorption Voltage), floating charge |
| System type | DC12V/24V/36V/48V Recognition automatically |
| System voltage automatic recognition | 12V system (DC9V-DC15V) |
| 24V system (DC18V-DC29V) |
| 36V system (DC30V-DC39V) |
| 48V system (DC40VDC60V) |
| Soft start time | <1S |
| Dynamic response and recovery time | >98.1 % (Voc is 1.5 or 2 times than battery, then it's the best efficiency) |
| PV utilization | >99% |
| Input specification |
| VOC from PV( Make sure the Voc of PV meeting the requirement as right. Voc is 1.5 or 2 times than battery, then it's the best efficiency.) | 12V system (DC20VDC80V) |
| 24V system (DC37V-DC105V) |
| 36V system (DC50VDC160V) |
| 48V system (DC72VDC160V) |
| The maximum PV input voltage (Voc) | DC190V(The controller can't work at this voltage of long duration that will break controller. Please refer to the Input voltage from PV.) |
| The maximum PV input power (The total power rated of PV can't be over this watt that will break the controller.) | 12V system (720W) |
| 24V system (1440W) |
| 36V system (2100W) |
| 48V system (2800W) |
| Output specification |
| Selectable battery type(default is Sealed) | Vented/ Sealed / Gel / NiCd / Lithium battery (defined voltage for other battery by user) |
| Absorption Charging Voltage | Refer to Batteries charging reference |
| Floating Charging Voltage | Refer to Batteries charging reference |
| Overcharging protection voltage | 12V system (15V) |
| 24V system (30V) |
| 36V system (45V) |
| 48V system (60V) |
| Rated output current | 60A |
| Temperature Coefficient | ±0.02%/ °C |
| Automatic temperature compensation | 14.2V-(Max temperature-25 °C)*0.3 |
| Output voltage ripple-peak | 100mv |
| Output voltage accuracy | <±1% |
| Input Anti-intrusion protection | yes |
| Temperature Protection | 75°C |
| Temperature increased protection | Output power will reduce when it's more than 70 °C |
| Output power will be normal when it's less than 55 °C |
| Fan-on temperature | >40 °C |
| Fan-off temperature | <35 °C |
| Acoustic noise | <40dB |
| Cooling way | Forced air cooling |
| Components | Imported materials, Accord to EU standards, Industrial grade range. |
| Environmental requirements | Meet 2002/95/EC; No cadmium, hydrides, and fluorides |
| Security Level | Accord to CE, PSE, FCC, EMC, EN60950 |
| Electromagnetic Compatibility | Accord to EN6W00, EN55022, EN55024 |
| Enclosure | IP21 |
| Net weight(Kg) | 1.3 |
| Gross weight(Kg) | 1.6 |
