Poynting OMNI-296 Dual-Band Wi-Fi & CBRS Antenna

Enhance your Wi-Fi performance in demanding environments with the OMNI-296 a high-performance dual-band omni-directional antenna from Poynting.

*Please note that this is a Wi-Fi antenna to use for expanding Wi-Fi coverage and receiving Wi-Fi signal. It can be used on access points and routers with Wi-Fi external antenna ports. This is not an LTE/5G antenna for your router to improve incoming data signal. Check our available LTE & 5G antennas.

Included in the Box:

• 1x OMNI-296 Antenna

• 1x 5m HDF195 Cable - N-type Male to SMA Male

• 1x Wall & pole mounting bracket bundle

• 1x User-friendly installation guide

Key Features:

• Dual-band support: Operates on 2.4 GHz and 5 GHz Wi-Fi bands

• CBRS-ready: Covers 3.43.8 GHz for future 5G applications

• Medium Gain: Up to 7.5 dBi peak gain for superior signal quality

• Robust Design: Weatherproof (IP65), fire-resistant (UL 94-HB), and vandal-resistant

• Flexible Mounting: Wall or pole-mountable stainless steel bracket included




📡 Frequency Bands & Gain:

• 2.42.5 GHz: 6 dBi

• 3.43.8 GHz (CBRS): 7 dBi

• 5.06.0 GHz: 7.5 dBi




🛠 Applications:

• Small businesses & warehouses

• Construction sites & open-pit mines

• IoT & M2M (Machine-to-Machine) deployments

• Environments with high RF interference or machinery clutter




🌦 Built to Last:

• Operating temperature: -40°C to +80°C

• Wind survival: Up to 190 km/h

• Ingress protection: IP65-rated for outdoor/indoor use

• Connector: N-Type (Female)

• Size: 485mm x Ø71mm (excl. bracket)

• Weight: 0.75 kg (0.91 kg packaged)
