Features:
Power your PC¿s / Monitors / DSTV / TV¿s
Simulated Sine Wave Inverter
Build-in AVR for Voltage Regulation
Wide Input Voltage Range 90
280 VAC - 24V DC
3 x 16A normal SA Wall sockets
Overload and Short Circuit Protection
LCD Display with Comprehensive Information
Specifications:
Capacity - VA: 2400 W: 1440
Input Voltage: 230 VAC
Acceptable Voltage Range: 90 - 280 VAC
Frequency: 50 Hz / 60 Hz (Auto Sensing)
Output - 50 Hz / 60 Hz (Auto Sensing): 230 VAC +- 10%
Efficiency (Peak): 85%
Transfer Time: 20 ms (Typical)
Waveform (Battery Mode): Simulated Sine Wave
Battery and AC Charger
Battery Voltage: 24 VDC
Floating Charge Voltage: 20.4 VDC +-2%
Low Battery Alarm Voltage: 20.4 VDC +-2%
Shutdown Voltage: 19.8 VDC +-2%
Overcharge Protection: 20.0 VDC +-2%
Maximum Charge Current: 10 / 20 A (Selectable)
Protection - Full Protection: Overload, Short Circuit and Polarity Reverse Protection
Physical Dimensions D x W x H (mm): 300 x 360 x 88
Net Weight (kg): 7.4
Operating Humidity: 0 to 90% Relative Humidity (Non-Condensing)
Operating Temperature: 0 C to 40 °C
Storage Temperature: -15 C to 50 °C
Output Provided: 3 x 16A SA Socket
Expected Run times:
