Specification:
Brand: PTK
Model: 8828 SSG-D
Gear Material: Stainless Steel Gear
Case Material: CNC Al Alloy
Operating Temperature: -15°C ~ +70°C
Operating Travel: 180° ± 10°
Refresh Rate: 333Hz
Net Weight: 58g
Pulse Width: 500 To 2500 µSec
Motor Type: Brushless Motor
Dead Band: 2 µs
Neutral Position: 1520 µSec
Size: 35.5mm * 15mm * 36.4mm
Bearing: Double Ball Bearing
Operating Voltage: 4.8V ~ 8.4V
Wire: JR 300mm
Mechanical Limit Angle: No Limit
Programmable: Yes
Operating Speed @ 4.8V: 0.135 Sec/60°
Operating Speed @ 6.0V: 0.128 Sec/60°
Operating Speed @ 7.4V: 0.122 Sec/60°
Operating Speed @ 8.4V: 0.105 Sec/60°
Stall Torque @ 4.8V: 15 Kg-Cm
Stall Torque @ 6.0V: 19 Kg-Cm
Stall Torque @ 7.4V: 24 Kg-Cm
Stall Torque @ 8.4V: 28 Kg-Cm
Package included:
1 x RC Servo
