Processor | Intel Prescott / Conroe / Smithfield / Cedar Mill CPU ( LGA775 ) support Up to 1066 MHz FSB |
Chipset | North bridge : VIA P4M900 South bridge : VIA 8237A |
Memory | 2 DIMM slot DDR II 400 / 533 / 667 |
IDE Interface | 2 IDE Connectors Support Ultra DMA ATA 100 / 133 |
VGA Interface | PCI Express x16 slot |
Audio Interface | HD Audio 2 Channel or 8 Channel |
Expansion Slots | 1 PCI Express x16 1 PCI Express x1 2 PCI |
LAN* | 10 / 100 or 1000 Mbps ( option ) |
IEEE 1394 * | 2 ports VIA6308( option ) |
Serial ATA | 2 ports |
USB 2.0 | 8 ports |
Dimension | microATX Form Factor |
Standard I / O | 1 x PS2 Connectors 1 x HD Audio connector : MIC-in , Line-in , Line-out ( for 2 channel ) 1 x HD Audio connector : MIC-in , Line-in , Line-out , Front L/R , Rear L/R , Center + Sub ( for 8 channel ) 1 x COM port , 1 x VGA port 1 x ( 1 x RJ45 + 2 x USB2.0 ) 1 x ( 2 x USB2.0 ) 1 x Parallel port |
