*** Description ***
---> brief introduction :
The keyboard controller can control high speed dome cameras , slow some camera , zoom camera , decoders , etc. The electric outlet between the controlling keyboard and the receiving terminal is EIA/RS - 485 , which enables the keyboard to control as many as 128 dome cameras or other terminals within a maximal communication range of 1.5 Km.
---> technical data :
---> Baud rate : 1200bps , 2400bps , 4800bps , 9600bps , 19200pbs , 38400pbs
---> Protocol : Pelco - D , Pelco-P , SAMSUNG , AD , PANASONIC
---> Communication : RS - 485
---> power input : DC 12V / 500mA
---> Communication distance : max 1500m
---> Can control max 128 speed domes
---> Password setup function
---> Ambient Temperature : 0 C ~ 60 C
---> Relative Humidity : 90%RH
--->DImension : 205mm x 168mm x 48mm
