Pure Sine Wave Inverter 12V DC 600W RCD OEINVPAR6

OSRAM POWERinvert PRO is an extensive range of professional heavy duty inverters for remote working. Available in either Pure Sine Wave or Modified Sine Wave for both 12V and 24V applications.OSRAM POWERinvert Pro inverters take the 12V or 24V DC vehicle electrical supply and invert into 230V AC mains power to run and operate electrical equipment from service vehicles. Pure Sine Wave Inverters produce a sine wave with the same frequency as mains power, with no distortion, to power sensitive electronics.Modified Inverters have distorted frequency, meaning they will power less complicated products such as fridges and power tools.

Product information
Number Of Phases Single

Electrical Data
Input voltage range (12V NOM) 9.5 V - 16.5 V
Input Current 59 A
Output voltage 200 - 240 Vrms

Continuous Power Rating (up to 12 hours) 600 W
Peak Amps 118
No Load Current < 1.5 A

Peak Power Rating (up to 200ms) 2 * rated power for 0.2s

Physical Attributes & Dimensions
Height 90.0 mm

Dimensions & weight
Input Cable Gauge / Length 600mm, 14mm^2

Lifetime Data
Guarantee 2 years

Additional product data
Battery Connection Terminal Nut & Bolt
Operating Temperature -25 +45 °C
Efficient at 75% load 90 %

Low Battery Alarm Yes
Low Battery Shutdown Yes

Outpur Waveform Pure Sine
Output Frequency 50 or 60 Hz

Power Saving Mode Yes
Power Saving Mode Current < 0.2 A

Programmable features
Thermal Protection Yes

Certificates & standards
Standards
CE / E- Mark
