GPU
RX 570, 14 nm FinFET
4th Graphics Core Next (GCN)
Engine Clock
Up to 1284 MHz, Boost
Stream Processors
2048
Memory Size/Bus
8GB GDDR5/256-bit
Memory Clock
7000 MHz effective
Displays
Maximum 5 Outputs
Interface
PCI-Express 3.0
Resolution
DisplayPort: 5120×2880@60Hz
HDMI: 4096×2160@60Hz
DVI:2560x1600@60Hz
Output
1x DVI-D
2x HDMI
2x DisplayPort 1.4
BIOS Support
UEFI
API
OpenGL® 4.5
OpenCL 2.0
DirectX® 12
Shader Model 5.0
Game Index
1080p gaming
Sapphire Features
Dual-X Cooling
Long Life Dual Ball Bearing Fans
Intelligent Fan Control III
Quick Connect System
Long Life Capacitor
Back plate Black
Diamond 4 Chokes
Fuse protection
AMD Features
Radeon VR Ready Premium
Radeon Software
Radeon FreeSync Technology
AMD LiquidVR Technology
4th Gen GCN Architecture
Radeon Chill
Radeon ReLive DirectX® 12 Technology
AMD Eyefinity Technology (Gaming)
AMD App Acceleration
AMD CrossFire Technology
AMD CrossFire (Bridgeless)
3rd Gen 14nm Process Technology
OpenCL 2.0
OpenGL 4.5
AMD PowerTune Technology
TrueAudio Next
Unified Video Decoder (UVD)
Video Code Engine (VCE)
Virtual Super Resolution
The Vulkan® API
Cooler Type
Dual-X Cooling Technology
Two ball bearing fan
Fan Quick Connect
Form Factor
2 Slots Occupied
230X125X40 Dimension/mm
Power Consumption
<180W
OS
Windows® 11, 10, Windows® 7, 64bit operating system required
System Requirement
500 Watt or greater power supply (Recommended)
1 x 8-pin Power Connector
PCI Express® compliant motherboard with one x16 graphics slot
