Radiall (R113182000) RF / Coaxial Connector, MCX Coaxial, Right Angle Plug

RF / Coaxial Connector, MCX Coaxial, Right Angle Plug, Crimp, 50 ohm, RG188,RG316, BrassProduct OverviewThe R113182000 is a right angle MCX Plug with gold over nickel plated brasscenter contact, gold over nickel plated beryllium copper outer contact, goldover nickel plated brass body for 2.6/50 S cable. This MCX series plug has PTFEinsulation, cable mounting and crimp termination. The MCX series connectorutilizes the SMB series electrical line and features a particularly simple,compact and robust interface. The MCX series is 30% smaller than the SMB. TheMCX series connector helps to miniaturize equipment. It optimizes PCB layoutswith its range of models for PCBs including surface mount and press-fitreceptacles.Subminiature coaxial connectorPush-pull snap-on matingComplies with specification CECC 22220-55 to 155°C Temperature rangeApplicationsAerospace, Defence, Military, WirelessProduct InformationConnector Type: MCX CoaxialConnector Body Style: Right Angle PlugCoaxial Termination: CrimpImpedance: 50ohmCoaxial Cable Types: RG188, RG316Contact Material: BrassContact Plating: Gold Plated ContactsFrequency Max: 6GHzConnector Mounting: Cable MountProduct Range: -
