Raspberry Pi 3 Model B+

The Raspberry Pi 3 Model B+ is the latest product in the Raspberry Pi 3 range, boasting a 64-bit quad core processor running at 1.4GHz, dual-band 2.4GHz and 5GHz wireless LAN, Bluetooth 4.2/BLE, faster Ethernet, and PoE capability via a separate PoE HAT.

The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced wireless LAN compliance testing, improving both cost and time to market. The Raspberry Pi 3 Model B+ maintains the same mechanical footprint as both the Raspberry Pi 2 Model B and the Raspberry Pi 3 Model B.

We only stock UK made Raspberry Pi's manufactured in Sony's Pencoed factory in South Wales.

Please Note. It is recommended to use a 2.5A Power Supply with the Raspberry Pi 3 B+.

Specifications

• Processor
  • Broadcom BCM2387B0 chipset.
  • 1.4GHz Quad-Core ARM Cortex-A53 (64Bit)
• Connectivity
  • 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2, BLE
  • Gigabit Ethernet over USB 2.0 (maximum throughput 300Mbps)
  • 4 × USB 2.0 ports
• GPU
  • Dual Core VideoCore IV® Multimedia Co-Processor. Provides Open GL ES 2.0, hardware-accelerated OpenVG, and 1080p30 H.264 high-profile decode.
  • Capable of 1Gpixel/s, 1.5Gtexel/s or 24GFLOPs with texture filtering and DMA infrastructure
• Memory
  • 1GB LPDDR2
• Operating System
  • Boots from Micro SD card, running a version of the Linux operating system or Windows 10 IoT
• Dimensions
  • 85 x 56 x 17mm
• Power
  • 5V/2.5A DC via micro USB connector
  • 5V DC via GPIO header
  • Power over Ethernet (PoE) enabled (requires separate PoE HAT)

Connectors

• Ethernet
  • 10/100 BaseT Ethernet socket
• Video Output
  • HDMI (rev 1.3 & 1.4)
  • Composite RCA (PAL and NTSC)
• Audio Output
  • Audio Output 3.5mm jack
  • HDMI
  • USB 4 x USB 2.0 Connector
• GPIO Connector
  • 40-pin 2.54 mm (100 mil) expansion header: 2x20 strip
  • Providing 27 GPIO pins as well as +3.3 V, +5 V and GND supply lines
• Camera Connector
  • 15-pin MIPI Camera Serial Interface (CSI-2)
• Display Connector
  • Display Serial Interface (DSI) 15 way flat flex cable connector with two data lanes and a clock lane
• Memory Card Slot
  • Push/pull Micro SDIO

The Raspberry Pi 3 Model B+ will remain in production
until at least January 2023.

WARNINGS

• This product should only be connected to an external power supply rated at 5V/2.5 A DC. Any external power supply used with the Raspberry Pi 3 Model B+ shall comply with relevant regulations and standards applicable in the country of intended use.
• This product should be operated in a well-ventilated environment and, if used inside a case, the case should not be covered.
• Whilst in use, this product should be placed on a stable, flat, non-conductive surface and should not be contacted by conductive items.
• The connection of incompatible devices to the GPIO connection may affect compliance, result in damage to the unit, and invalidate the warranty.
• All peripherals used with this product should comply with relevant standards for the country of use and be marked accordingly to ensure that safety and performance requirements are met. These articles include but are not limited to keyboards, monitors, and mice when used in conjunction with the Raspberry Pi.
• The cables and connectors of all peripherals used with this product must have adequate insulation so that relevant safety requirements are met.

SAFETY INSTRUCTIONS
To avoid malfunction of or damage to this product, please observe the following:

• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any source; the Raspberry Pi 3 Model B+ is designed for reliable operation at normal ambient temperatures.
• Take care whilst handling to avoid mechanical or electrical damage to the printed circuit board and connectors.
• Whilst it is powered, avoid handling the printed circuit board, or only handle it by the edges to minimize the risk of electrostatic discharge damage.
