RAYSHARP 8CH CCTV H.264 D1 DVR

Product Description

8CH H.264 D1 DVR

TECHNOLOGY:
H.264 video compression
Embedded Linux technology
ADPCM audio compression format
Design for SATA HDD technology (HDD x 1/ not included)
HEXAPLEX operation – Record, Live view, Playback, Backup, Network Control & Mobile Phone Monitoring

VIDEO
Real-time monitoring for all channels @ D1
8 channels video inputs
D1/HD1/CIF video recording resolution adjustable
Support Nine channels, Quad, Single channel & Auto Sequence display for live view

AUDIO
8 channels audio inputs & 1 channel audio output

DISPLAY OUTPUT ( WITH VGA OUTPUT)
VGA x 1 with selectable 800 x 600, 1024 x 768, 1280 x 1024, 1440 x 900 or 1920 x 1200 screen resolution
Graphics & Windows OSD interface

RECORDING
Frame rate adjustable for each channel
Support Pre Recording
Multiple recording & alarm modes
Motion detection: settable area & sensitivity
Programmable recording video quality for each channel

PLAYBACK
Playback search by time & date or event
Support 8 channel, 4 channel and single channel playback

NOTIFICATIONS & ALARM BUZZER
Email notifications (1 email account) & buzzer alert
OSD screen message event alert on live display monitor

VIDEO / AUDIO BACK-UP
Video & Audio back-up to any USB 2.0 storage device

NETWORK & REMOTE ACCESS MONITORING FUNCTION
Remote access view, playback, DVR setup, back-up video files & record via IE
Support CMS monitoring up to 49CH video
Control PTZ camera Zoom, Focus, Iris, Auto-pan, Preset SEQ & Preset memory function
Support PPPoE, DHCP & Static IP address & DDNS
Support 3 users simultaneously for remote access view
Mobile Phone view based on Symbian S60 3rd, Symbian S60 5th, Windows Mobile, iPhone, Blackberry & Android

PTZ CONTROL FUNCTION
Support every channel as PTZ camera
On video screen mouse click PTZ camera pan/tilt control
Built-in RS485 PTZ camera communication data input

I/O INPUT & OUTPUT
Built-in 8CH sensor inputs, 1CH alarm output

PASSWORD & SECURITY
Password protection for menu settings & remote access view

OPERATION
PC mouse & IR remote control operation (included inside)

SPECIAL FUNCTION
Support convert / hide camera display function
System self-recovery with recording & settings memory after power restores
Digital zoom capabilities
Video brightness, contrast, hue & saturation adjustable for each channel
Support daylight saving mode function
Support professional grade CMS
Support set up privacy zone
HDD can be overwritten by days between 1 and 60 days
Support video enlarged – display full screen automatically when alarm is triggered
Support log search
Flexible Customization to meet market requirements
