| Main centres: | 1-3 business days |
| Regional areas: | 3-4 business days |
| Remote areas: | 3-5 business days |
| RATED POWER | 5000VA/ 5000W |
| Parallel Capability | Yes, 9 units |
| INPUT | |
| Voltage | 230 VAC |
| Voltage Range | 110-280 VAC |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
| Output THDv | <3% for linear load, <8% for non-linear load |
| Surge Power | 10000VA for 5 sec. |
| Efficiency (Peak) | 93 % at Line Mode, 90% at Battery Mode |
| Transfer Time | 0 ms |
| Waveform | Pure sine wave |
| BATTERY & AC CHARGER | |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 66 VDC |
| SOLAR CHARGER & AC CHARGER | |
| Maximum PV Array Power | 4000W |
| MPPT Range @ Operating Voltage | 60VDC ~ 115VDC |
| Maximum PV Array Open Circuit Voltage | 145VDC |
| Maximum Solar Charge Current | 80A |
| Maximum AC Charge Current | 60 A |
| Maximum Charge Current | 140A |
| Maximum Efficiency | 98% |
| Standby Power Consumption | 2 W |
| PHYSICAL | |
| Dimension, D x W x H (mm) | 140 x 300 x 512 |
| Net Weight (kgs) | 12.2 |
| OPERATING ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | 0°C - 55°C |
| Storage Temperature | -15°C - 60°C |
