Specification:
Brand: ATOMRC
Model: F405 NAVI Delux
MCU: STM32F405RGT6
IMU: BMI270
Black Box: 16Mb
Servo BEC: 5V/6V/7.2V
VTX BEC: 9V
CAM BEC: 12V/5V
PWM Output: PWM*11
Uart: Uart+6
External USB-C Port: Buzzer/BOOT/Type C
LED: WS2812 LED Strip
Firmware: ArduPilot:ATOMRC F405 NAVI Delux; INAV:ATOMRC F405 NAVI Delux
Ammeter: 200A
Voltage Input: 12~30V (3~6S Lipo)
Mount Hole: 30×24x3 (mm)
Weight: 29g
Size: 50×31×17 (mm)
Feature:
1. Powerful MCU for Smooth Control: Integrated STM32F405RTG6 chip ensures high-speed processing and stable operation, ideal for INAV and ArduPilot firmware compatibility.
2. Built-in Bluetooth and WiFi Module: Equipped with Bluetooth module and WiFi functionality for convenient wireless parameter adjustments.
3. High
