Remote Control Relay Switch 1 channel DC 12V & 1 Remote:
Introduction:
Replace RF garage door remotes or other electrical controllers with this code learning programmable universal remote control. Learn how to program for garage door remotes or other remotely controlled needs. A full remote controller replacement is often the better option than to repair faulty ones.
Uses: Electric gates, Electric windows, Garage doors, Lifting equipment, Robotics, Security systems, Vehicle central locking, Vehicle sun roofs, etc.
Coding: 16 different codes, if you have more, it will delete the code at the beginning that you have set.
Receiver Specifications:
Channels: 1
Working voltage: 12V DC
Dual mode: momentary/toggle
Power consumption: <10mA
Output Current: <10A
Sensitivity: ≥-95dBm
Frequency: 315MHz
Dimension: 65 x 38 x 22mm
Remote Control Specifications:
Voltage: DC 6V
Frequency: 315MHz
Range: 50-100 meters (Open Space)
Current: < 15mA
Shock Resistance: 4.7
Size: 62x34x10mm
Bottom: ON/ OFF
Learning Method:
1.After power on, the indicator light is always on. Then, you press the learning button for 2 or 3 seconds, and the indicator light will power off.
2.Release the learning button, and press the any key of remote control.
3. After the indicator light flashes 5 times, it shows that you have successfully set the code.
Remove Method:
Press the learning button about 8 seconds, the indicator light returns to being powered on showing the learning code has been removed.
