| Brand Name: Apexis | Model Number: APM-J011-WS | |
| Type: IP Camera | Style: robot | Sensor: CMOS |
| Technology: Infrared | Special Features: pan/tilt | Wireless IP Camera: Wireless Network Camera |
Specifications
PT Wireless IP Camera
(1)Support Iphone, Smartphone, 3Gphone
(2)Two way audio
(3)Pan/Tilt, IR night Vision
(4)I/O alarm
PT Wireless IP Camera, Wireless Network Camera,Pan/Tilt IP Camera, High quality wifi ip camera, support Iphone
Model: APM-J011-WS
Features:
(APM-J011-WS)
> Powerful high-speed video protocol processor
> MJPEG video compression
> Support wireless network (Wi-Fi/802.11/b/g)mobile
> Support two-way audio function
> High-sensitivity CMOS sensor
> Resolution:640 x 480(VGA), 320 x 240(QVGA)
> Video Frame Rate:30fps(QVGA), 15fps(VGA)
> Minimum Illumination:0.5Lux @ F2.0
> IR night vision(Range:10~15m)
> Remote Pan/Tilt rotate(Horizontal:220°,Vertical:90°)
> Supports control P/T through IP network
> Supporting up to 4 users online simultaneously
> Supporting image snapshot
> Supports power up action
> Built-in 10M/100M auto MDI/MDIX Ethernet interface
> Frame ratio or Bandwidth can be adjusted
> Light Frequency:50Hz, 60Hz or Outdoor
> Multi-level users management and passwords definition
> Built-in Web server,supports remotely viewing and/or management the
camera form a standare Web browser on any computer,anywhere,and at anytime
> Supporting Dynamic IP (DDNS)and UPnP LAN and Internet(ADSL,Cable Modern)
> Giving alarm in cause of motion detection
> Supporting image snapshot
> Supporting multiple network protocols:HTTP/TCP/IP/UDP/STMP/DDNS/
SNTP/DHCP/FTP
> Built-in RTOS,supports software download and configuration online,
that is convenient for camera updating and management
Specification:
| Model | APM-J011-WS |
| Image Sensor | |
| Sensor | ¼" Color CMOS Sensor |
| Resolution | 640 x 480 Pixels |
| Lens | f: 6mm, F 2.0 (IR Lens) |
| Viewing Angle | 60 Degree |
| Minimum Illumination | 0.5Lux @ F2.0 |
| Video/Image Setting | |
| Video Compression | MJPEG Video Compression |
| Video Frame Rate | 30fps(QVGA), 15fps(VGA) |
| Resolution | 640 x 480(VGA), 320 x 240(QVGA) |
| Light Frequency | 50Hz, 60Hz or Outdoor |
| Video Parameters | Brightness, contrast |
| Audio talk-back | Built-in Mic |
| Communication | |
| System Interface | 10Base-T/100Base-TX Ethernet Port |
| Supported Protocol | TCP/IP,DHCP,SMTP,HTTP,DDNS,UPNP,PPPoE,FTP,DNS |
| Wireless LAN | Support wireless network (Wi-Fi/802.11/b/g)mobile |
| WEP Encryption | Disable / 64 bit / 128 bit |
| WPA Encryption | TKIP / AES |
| Physical / Environment | |
| Pan/Tilt Angle | Horizontal:220 degree & Vertical: 90 degree |
| Alarm Input | 1 Channel on/off input |
| Alarm Output | 1 Channel relay output |
| Power Supply | 5VDC/1A External Power Adapter |
| Power Consumption | 5W(Max.) |
| Operate Temperature | (0°C ~ 55°C) |
| Storage temperature | (-25°C ~ 55°C) |
| PC System Requirement | |
| CPU | 2.0GHZ or above |
| Memory Size | 256MB or above |
| Display Card | 64M or above memory |
| Supported OS | Microsoft Windows 98/ME/2000/XP/Vista/7 |
