RETEVIS HD1 136-174&400-480MHz&76-107.95MHz 3000CHS Dual Band DMR Digital Waterproof Two Way Radi...
New
Shipping
Standard courier shipping from R30
R30 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30 surcharge. This will be calculated at checkout if applicable.
Check my rate
Check my rate
Ready to ship in
The seller has indicated that they will usually have this item
ready to ship within 15 business days. Shipping time depends on your delivery address. The most
accurate delivery time will be calculated at checkout, but in
general, the following shipping times apply:
Standard Delivery
| Main centres: | 1-3 business days |
| Regional areas: | 3-4 business days |
| Remote areas: | 3-5 business days |
Get it now, pay later
Seller
Buyer Protection
Product details
Condition
New
Location
International
Product code
EDA001528301A
Bob Shop ID
602471981
1. Use the digital mobile radio (DMR) layer 2 standard protocol. It is compatible with other brands and models of popular MOTO TRBO series Tier I and II that use standard encryption and other DMR-enabled radios. It is also compatible with any existing analog two-way radios operating on supported UHF and VHF frequencies and can be easily ported to digital technology. Almost all operations can be done through the wireless keyboard
2. It also has many functions, such as send/receive interrupt, CTCSS&DCS, VOX, surveillance, emergency alert, scan, key lock, TOT, password lock, power saving, remote kill/stun/activate, analog and digital combination, LED Indicator lights, voice prompts, etc.
3. Frequency: 136-174&400-480MHz&76-107.95MHz (receive only)
4. Channel: 3000
5. Working voltage: 7.4V DC
6. Battery capacity: 3200mAh
7. Antenna impedance: 50 ohms
8. Size: 150 x 64x 40mm
9. Weight: 360g (including battery)
Transmitter:
1. Power: UHF: 8w: 4w: 1w, VHF: 10w: 5w: 1w
2. Frequency stability: +/-1.0ppm
3. FM modulation mode: 12.5KHz@11K0F3E 25KHz @ 16K0F3E
4. Modulation distortion: less than 5%
5. Vocoder: AMBE + 2TM
6. Adjacent channel power: 60dBm@12.5KHz 65dBm @ 25KHz
7. Audio response: +1 to -3dB
8. Digital protocol: ETSI-TS102 361-1, -2, -3
Receiver:
1. Digital sensitivity: 0.30uV / -117dBm (BER 5%), 0.70uV / -110dBm (bit error rate 1%)
2. Adjacent channel selectivity: TIA603C: 65dB ETSI: 60dB
3. Spurious response: TIA603C: 75dB ETSI: 70dB
4. Audio response: +1 to -3dB
5. Rated audio distortion: less than or equal to 3% (type)
6. Audio power: greater than or equal to 500mW
