RF Wireless Remote Radio Control Switch 8 Channels

Features:

• Control Lights, TV, Motors, Fans, Cameras, Video Signals, Audio Signals, Electric Doors/Locks/Windows/Curtains/Cars or Other Appliances with voltage AC 110~240V or DC 0~28V.
• You can turn on/off the receiver with transmitter (remote control) from any place, the wireless signal can pass through walls, floors, and doors.
• Reliable control: The transmitter (Encoding) and the receiver (Decoding) use an 8-bits code.
• Transmitting Frequency: 315MHz

Technical Specification:

Receiver:

• Channel: 8 CH Control

• Types: Toggle, Momentary, Latched.

• Decode: Learning code

• Power Supply (Operating Voltage): DC12V

• Relay: 10A/120VAC, 5A/220VAC, 20A/14VDC

• Work Voltage Range of Relay: AC 110~240V or DC 0~28V

• Receiver Board Size: 69mm x 48mm x 20mm

• State current: 6mA

Transmitter (Remote control):

• Channel (keys): 8CH

• Remote control distance: Up to 500m. (Line of sight)

• Encode: Fixed code, Soldering

• Power Supply: 1 x 23A-12V battery (included)

Control type:

• Toggle: Press->On; Press again->Off

• Latched: Press->On; Press other button->Off

• Momentary: Press and hold->On; Release->Off

Included in package:

• 1 x 8CH Receiver (8 Channels / Three Control Types /DC12V).

• 1 x Transmitter (Battery included)
