How to use
Connect the RFID reader to PC’ USB port with the USB cable.
After installation successfully, open “Excel “or other application program to read the RFID Tag and the ID will be shown on the screen.
Main Features:
Support: EM4100 or compatible ID card/tags (64bits,Manchester codes)
Work Frequency: 125Khz
Built-in transceiver antenna
Power by USB interface and no external power is needed;
Plug and play. No driver is needed under XP , Vista and windows 7
Interface: USB Port
Output format : 10 digit decimal card number
Operating Temperature: -10'C ~ +70'C
Store Temperature: -20'C ~ +80'C
Maximum Operating Humidity Relative humidity: 0 ~ 95%
Package included
125Khz EM4100 reader with USB cable x 1
