Ribbon Cable 2651 VW-1 8 Way Flat per Metre ***LOCAL STOCK***
Sold

Ribbon Cable 2651 VW-1 8 Way Flat per Metre ***LOCAL STOCK***

New 31 were available
R16.35
Shipping
R65.00 Standard shipping applies to orders under R100.00, in most areas in South Africa. R35.00 Standard shipping applies to orders over R100.00. Some areas may attract a surcharge surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 5 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Buyer protection
Get it now, pay later

Product details

Condition
New
Location
South Africa
Customer ratings:
Bob Shop ID
459596752

Ribbon Cable 2651 VW-1 8 Way Flat per Metre



Colour: Grey with red polarity stripe.
UL Style: 2651.
Flammability Rating: UL VW-1.
AWG: 28 T.C.
Nom. Wall: 0.25 mm
Height: 0.89 mm +/- .08
Center to Center Spacing: 1.27 mm +/- .05
Dielectric Withstand Voltage: 2000 VRMS.
Insulation Resistance: 1010 OHMS/10 Ft min.
Capacity Nom: 15 PF/FT. (G.S.G.)
Propagation Delay: 1.4 ns/ft. (G.S.G.) nom.
Temperature Rating:     105°C.
Current Rating: 1 AMP.
Impedance: 105 Ohms nom. (G.S.G.)
Voltage Rating: 300 VRMS



This item is available in stock and is not drop shipped. This avoids delays, customs charges and extra VAT.
