Brand-new, unused, unopened, undamaged item in its original packaging
FREE SHIPPING OPTION!!!
This item is in stock
Features
- Custom 10-AWG nickel plated push terminals
- Dual linear spider with embedded 16 AWG tinsel leads
- Extended pole piece and bumped backplate
- High excursion Poly-ether-ester surround
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Kevlar Fiber reinforced semi-pressed paper cone and ABS/Acrylic dustcap
- Protective PVC textured magnet cover
- Reversable diamond cut cast aluminum trim ring
- Vented spider cavity
Specifcations
Size: 12"
Impedance: 2-Ohm x 2
Power Handling: 500 Watts RMS (1000 Watts Max)
Voice Coil Diameter: 2.5" 4-Layer (6.35 cm)
Motor Size: 102 oz. double stacked
Speaker Connector: Dual 10 AWG compression
SPL: (1W/1M) 85 dB
Mounting Depth: 6.75 in. (17.15 cm)
Rec. Sealed Enclosure: 1.0 cu. ft. (28.88 liters)
Range: 0.75 cu. ft.- 1.25 cu. ft.
Range: (21.24 liters - 35.40 liters)
Rec. Vented Enclosure: 1.79 cu. ft. (50.69 liters)
Vented Tuning Frequency 40 Hz
Port: (1) 4" diam. x 10" long
Port: (1) 10.16 cm x 35.56 cm
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. This means your speaker has the capacity to handle power under continuous demand, not instantaneous power handling, that over time, can damage voice coils.
