ENGINEERING WORLD is the importer of these and other laser tools and is therefore able to offer these tools to the end user at great value for money as there is no middleman involved.
�
ROTARY LASER KIT 6015
�
The rotating laser is a laser marking tool that makes it simple and cost effective to mark out laser lines vertically and horizontally.
This tool comes in a practical carry case which includes tripod, wall bracket and power supply, as well as 4 rechargeable batteries.
Once the rotating laser is mounted on the tripod and levelled it will give a laser marker on the surface, which can be rotated by hand and by motor at variable speeds.
The higher the speeds the more continuous the lines will become.
This operation can be done by means of battery power or by means of power supply.
For vertical lines the rotating laser can be laid on it�s side.
The tripod will be able to adjust to different heights and can also be used on stair cases.
For higher marking positions a bracket is supplied with the unit, which can be mounted to the wall surface by means of screw or nail fixture.
�
Some practical uses
�
Hanging of expanded ceilings, standard ceilings and fitting of cornices,
Raised flooring installations,
Plumbing installations, electrical installations,
Painting of lines, mounting of picture rails,
Tiling, panelling,
Marking out positions of down lighters and other lights,
Installing dry walling and partitioning,
Installing racking and shelving,
And many other applications.
�
Technical data
�
2 horizontal levelling vials
1 vertical levelling vial,
Rated working voltage DC4.8V (4xAA type 1.2V rechargeable batteries)
������������ ���������������������� ��-DC6V (4x AA type 1.5 V standard batteries)
Laser: 1mW, 630-680nM,
Laser class2 according to DIN EN 60825-1:1997
Class 3 protection
Rotating speed: 0-300 rpm
Precision: +/- 0.5mm/M
Adapter input 230V, 50 Hz, output DC6V, 300mA, Class2
Charging time 2-4 hours
Operating distance (in house) +/- 10 Metres
�
