Specification:
Display
Resolution
3,840 x 2,160 (16:9)
Contrast Ratio (Dynamic)
Mega
Viewing Angle (H/V)
178/178
Color Gamut
72% (NTSC)
Haze
25%
H-Scanning Frequency
30~81kHz
Maximum Pixel Frequency
594MHz
V-Scanning Frequency
48~75Hz
Brightness (Typ.)
500 nit
Orientation
Landscape/Portrait
Panel Type
VA/IPS
Active Display Area
941.184 (H) x 529.416 (V)
Response Time (ms)
8ms
Operation Time Support
24/7
Contrast Ratio
4,000:1
Connectivity
HDMI In
3
DP In
1
Version of DP
1.2
USB
2
Version of HDCP
2.2
IR In
Yes
Audio Out
Stereo Mini Jack
RS232 In
Yes
RS232 Out
Yes
RJ45 In
Yes
WiFi
Yes
Version of HDMI
2
Bluetooth
Yes
Power
Power Supply
AC100-240V 50/60Hz
Power Consumption (On Mode)
121 W
Power Consumption (Sleep Mode)
less than 0.5W
Features
Key
UHD Signage with Built-in MagicInfo S10, SSSP 10.0
Special H/W
2nd Gen. B2B Design
Center IR
Temperature Sensor
Ambient Sensor
Auto Level
Wi-Fi(2.4/5.0GHz dual) & BT
Special S/W
Signage New Home
Workspace (Microsoft371/VMWare/RDP)
Custom Home
Auto Source Switching & Recovery
Dicom Simulation Mode
Director Mode
SmartView+
Upgradable Web-Engine
Tizen Enterprise Platform
Video Conference Solution
Smart Calibration
Internal Player
Processor
CA73 1.6GHz Quad-Core
Operating System
Tizen 7.0
Storage (FDM)
16 GB(10 GB available)
Dimensions
Set Dimension (WxHxD)
969.5 x 557.8 x 28.5 mm
Package Dimension (WxHxD)
1093 x 667 x 126 mm
Weight
Set Weight (kg)
8.8
Package Weight (kg)
11.3
Set Weight (lbs)
19.4
Product Weight (lbs)
24.9
Accessories
Included in Box
Quick Setup Guide, Warranty Card, Power Cord RS232C(IN) Gender Remote Controller & Batteries
Optional Stand
STN-L4355C
Optional Mount
WMN-B50SC
Mechanical Specs
VESA Mount
200 x 200
Frame Material
Non-Glossy
VESA Mount Screw (Min~Max)
M8, 12~14mm
Bezel Width (mm)
11.5(Even)
Set Dimension (Inches)
38.2 x 22 x 1.1
Package Dimension (Inches)
43 x 26.3 x 5
SoC
OS Version
Tizen 7.0
Flash Memory Size
16GB
Optional Feature
Mount
WMN-B50SC
Certification
Safety
60950-1 / 62368-1
EMC
Class B
Environment
ENERGY STAR 8.0, EPEAT
IP Rating
IP5x
Security
802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
Display Panel
Screen Size
43
Measured
42.5
Contrast Ratio (Typ.)
4000:1 (* IPS - 1200:1)
Pixel Pitch (mm)
0.245 x 0.245mm
Connectivity/Sound
VIDEO Input
DP 1.2 (1), HDMI 2.0 (3)
HDCP Input
HDCP2.2
USB Input
USB 2.0 x 2
AUDIO Output
Stereo mini Jack
WiFi / BT
O / O
External Control
RS232C(in/out), RJ45
Speaker
10W 2ch
Operating Condition
Temperature (Celsius)
0?~ 40?
Temperature (Fahrenheit)
32 ~ 104
Relative Humidity
10~80%
