NETWORK Technology
GSM/ HSPA / LTE
LAUNCH Announced 2019, February 25
Status Available. Released 2019, March 18
BODY Dimensions 158.5x 74.7 x 7.7 mm (6.24 x 2.94 x 0.30 in)
Weight 166 g (5.86 oz)
Build Glass front (Gorilla Glass 3), plasticback, plastic frame
SIM Single SIM (Dual Sim)
DISPLAY Type Super AMOLED capacitive touchscreen, 16M colors
Size 6.4 inches, 100.5 cm2 (~84.9%screen-to-body ratio)
Resolution 1080 x 2340 pixels, 19.5:9 ratio (~403ppi density)
Protection Corning Gorilla Glass 3
PLATFORM OS Android9.0 (Pie), upgradable to Android 10, One UI 2.0
Chipset Exynos 9610 (10nm)
CPU Octa-core (4x2.3 GHz Cortex-A73 &4x1.7 GHz Cortex-A53)
GPU Mali-G72 MP3
MEMORY Card slot microSDXC (dedicated slot)
Internal 64GB 4GB RAM, 64GB 6GB RAM, 128GB 4GB RAM,128GB 6GB RAM
UFS2.1
MAINCAMERA Triple 25 MP, f/1.7, 26mm (wide), PDAF
8MP, f/2.2, 13mm (ultrawide), 1/4.0, 1.12m
5MP, f/2.2, (depth)
Features LED flash, panorama, HDR
Video 1080p@30fps
SELFIECAMERA Single 25 MP, f/2.0, 25mm (wide), 1/2.8, 0.9m
Features HDR
Video 1080p@30fps
SOUND Loudspeaker Yes
3.5mmjack Yes
COMMS WLAN Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot
Bluetooth 5.0, A2DP, LE
GPS Yes, with A-GPS, GLONASS, GALILEO, BDS
NFC Yes (market dependent)
Radio FM radio
USB 2.0, Type-C 1.0 reversible connector,USB On-The-Go
FEATURES Sensors Fingerprint (under display, optical), accelerometer, gyro,proximity, compass
ANT+
Bixbynatural language commands and dictation
BATTERY Non-removableLi-Po 4000 mAh battery
Charging Fast charging 15W
MISC Colors Black,White, Blue, Coral
Models SM-A505F, SM-A505FN, SM-A505GN, SM-A505G,SM-A505FM, SM-A505YN, SM-A505W, SM-A505X, SM-A505U, SM-A505GT, SM-A505U1,SM-A505G, SM-A505N
SAR 1.31 W/kg (head) 0.58 W/kg (body)
SAREU 0.27 W/kg (head) 1.39 W/kg (body)
TESTS Performance AnTuTu:144574 (v7)
GeekBench:5396 (v4.4)
GFXBench:8fps (ES 3.1 onscreen)
Display Contrast ratio: Infinite (nominal)
Camera Photo / Video
Loudspeaker Voice 68dB / Noise 71dB / Ring 82dB
Audioquality Noise -93.4dB / Crosstalk-92.3dB
Batterylife
Endurancerating 98h
