Samsung WM55H - Digital Flipchart for Business

Samsung WM55H - Digital Flipchart for Business Specifications

Series Name

Series Name WM55H

Display

Screen Size 55"

Panel Technology 60Hz E-LED

Resolution 3,840 x 2,160 (Landscape)

2,160 x 3,840 (Portrait)

Brightness 300nit (without glass), 220nit (with glass)

Contrast Ratio (Typical) 4700:1 (without glass)

Viewing Angle (H/V) 178:178

Response Time 8ms(Typ.)

Connectivity

Input VIDEO: HDMI 1

USB: USB 2 (ver 2.0 x2, Side 1, Sensor Assy 1)

Output TOUCH OUT: Touch Out 1 (Side, USB Upstream Type)

External Control Touch Input, RJ45 (not for User Control)

Sensor NFC, Acceleration sensor, Proximity Sensor

Power

Power Supply AC 100~240V 50/60Hz

Power Consumption (Typical/Max) Typ: 100 W/h, Max: 165 W/h

Power Consumption (Standby) 0.5 W/h

Environmental Conditions

Operating Temperature 0~ 40

Operating Humidity 10~80%

Features

Key Flip App

Special HARDWARE: Super Clear Coating, Temperature Sensor, Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded

SOFTWARE: Flip S/W

PLATFORM: Kant-M (Tizen 3.0)

Touchscreen Yes

Speaker Type Built in Speaker (10W x 2)

Touch

Type Advanced IR

# of Drawing 4 drawing

Touch Pen Type Passive Pen

Object Recognition Range 2mm/ 4mm / 8mm / 50mm

Touch Response Time 38ms ~ 46ms

(According to number of Multi Drawing )

Internal Player

Processor CA72 Quad(1.7GHz)

On-Chip Cache Memory L1 (I/D) : 32KB / 32KB

L2 (Unified) : 1MB

Clock Speed 1.7GHz CPU Quad

Main Memory Interface LPDDR4 1400MHz 64bit 3GB

Graphics 2D & 3D Graphics Engine

- Up to 1920x1080. 32bpp

- Supports OpenGL ES

Storage 8GB

(2.65GB Occupied by O/S, 5.35GB Available)

Multimedia Video Decoder: MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/ AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9

Audio Decoder: AC3 (DD), MPEG

IO Ports USB 2.0

Operating System Samsung Proprietary OS(VDLinux)

Dimensions

Packaging (W x H x D) 1469 x 924 x 210 mm

Weight

Product Weight 28.9 kg

Package Weight 34.9 kg

Optional Wall Mount Kit WMN-6575SD

Optional Stand STN-WM55H

Specialty Flip UX

Mechancial Specs

VESA Mount 400 x 400

Color Light Gray

Protection Glass Yes

Stand Type Moving Stand(Acc), Wall Mount

Rotation Available with Flip Stand

Power Cable Length 3m

Accessory Cover-Jack
