Samtec (CES-120-01-T-S) PCB Receptacle, Board-to-Board, 2.54 mm, 1 Rows

PCB Receptacle, Board-to-Board, 2.54 mm, 1 Rows, 20 Contacts, Through HoleMount, CESProduct OverviewThe CES-120-01-T-S is a 20-pole 1-row 2.54mm Closed Entry Low Profile SocketStrip with matte tin-plated phosphor bronze contacts and GF polyester insulator.The CES series closed entry low profile socket strip is compatible with TLW,TSW, MTLW, MTSW, HW, EW, ZW, HTSW, HMTSW and TSM series connectors.Orderable with single/dual rows (-S/-D options)Pitch spacing is 2.54mm (1 to 50 contacts per row) with straight orientationHigh operating temperature range of -55?C to 105?C for matte tin plated contactsBlack glass filled polyester insulator materialVoltage rating is 400VACContact resistance is 10mohmDual leaf contact systemComplies with UL E111594 and CSA 0908710000 standardsContact material is phosphor bronzeApplicationsIndustrialProduct InformationConnector Systems: Board-to-BoardPitch Spacing: 2.54mmNo. of Contacts: 20ContactsContact Termination Type: Through HoleConnector Mounting: Through Hole MountNo. of Rows: 1RowsProduct Range: CESContact Material: Phosphor BronzeContact Plating: Tin Plated Contacts
