Samtec (SSW-106-01-G-S) PCB Receptacle, Board-to-Board, 2.54 mm, 1 Rows

PCB Receptacle, Board-to-Board, 2.54 mm, 1 Rows, 6 Contacts, Through Hole Mount,SSWProduct OverviewThe SSW-106-01-G-S is a 6-pole 1-row 2.54mm Through-hole SQ Post Socket Stripwith 20?inch (0.51?m) gold-plated phosphor bronze contacts and LCP insulator.The SSW series straight pin socket strip compatible with DW, EW, HCMD, HCMS,HHSC, HMTSW, HTSS, HTSW, HW-SM, HW-TH LCW, MTLW, MTSW, PHT, TLW, TSM, TSS, TSSH,TSW, ZSS and ZW connectors.Orderable with single/dual/triple rows (-S/-D/-T/ -P/-Q options)Pitch spacing is 2.54mm (1 to 50 contacts per row) with straight orientationHigh operating temperature range of -55?C to 125?C for 20?" gold plated contactsBlack liquid crystal polymer (-S, -D) / black high temperature thermoplastic(-T) insulator materialComplies with UL E111594 and CSA 0908710000 standardsContact material is phosphor bronzeApplicationsIndustrialProduct InformationConnector Systems: Board-to-BoardPitch Spacing: 2.54mmNo. of Contacts: 6ContactsContact Termination Type: Through HoleConnector Mounting: Through Hole MountNo. of Rows: 1RowsProduct Range: SSWContact Material: Phosphor BronzeContact Plating: Gold Plated Contacts
