2048 Stream Processors
14 nm FinFET
4th Graphics Core Next (GCN)
1284 MHz Boost Engine Clock
PCI-Express 3.0
256 bit Memory Bus
GDDR5 Memory
1750 MHz, 7000 MHz Effective
8 GB Size
5 Display Outputs
1 x DVI-D
2 x HDMI
2 x DisplayPort
5120×2880@60Hz Pixel DisplayPort Resolution
2560x1600 (60Hz) Pixel Dual Link DVI Resolution
4096×2160@60Hz HDMI Resolution
APIOpenGL® 4.5
OpenCL 2.0
DirectX® 12
Shader Model 5.0
AMD CrossFire
FreeSync Technology
AMD Eyefinity
Quad HD Display (4K*2K Support)
AMD Xconnect ready
DirectX™ 12 Optimized
HDR Ready
Frame Rate Target Control
NITRO Fan Check
NITRO Quick Connect system
Intelligent Fan Control III
Black Diamond Choke 4
Radeon Chill
Radeon Relive
CoolingDual-X fans
Form Factor2 Part Slot Occupied
230(L)X 125(W)X 40 (H) Dimension /mm
Power Consumption<180W
OSWindows 10¿Windows 7¿
System Requirement500 Watt Power Supply (Suggestion)
1 x 8-pin AUX Power Connector
CD-ROM or DVD-ROM drive for installing software
PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
