1. High quality and stable performance: it's with a microprocessor controller.
2. 3.5" LCD color display, bigger menu window.
3. Channel picture, signal strength and signal quality can be showed on LCD
4. Screen after you set up your local DVB-S Parameter.
5. It's with auto-protection for LNB short-circuit.
6. It shows Azimuth and Elevation, CBER/VBER, S/N, signal strength and signal lock sound alarm.
7. Supports both AV IN and AV OUT for camera, LCD, etc.
8. Built-in large capacity 3000mAH Li-ion battery.
9. Matched with a protective bag for easier outdoor using.
10.Support language: English, German, French, Portuguese, Spanish, Italian, Dutch, Polish, Turkish.
11.English user manual is included in the CD disk.
System capabilities | Fully DVB-S comliant | Yes |
LNB/Tuner input | Connector | F type female |
Frequency range | 950MHz-2150MHz | |
Signal level | -65dBm~-25dBm | |
LNB power | 13/18V, max 350mA | |
LNB Switch control | 22KHz | |
DiSEqC | Ver 1.0/1.2 | |
Demodulator | Front end | QPSK |
Demodulation Range | 2Mbps~45Mbps | |
SCPC and MCPC capable | Yes | |
System resource | Processor | 32bit processor (133MHz) |
SDRAM | 4 x 16Mbyte | |
FLASH | 8Mbyte | |
Video decoder | MPEG2 |
