Seasonic SS-850AM M12II 850W Evo Edition 80 Plus Bronze Fully Modular Power Supply

Seasonic SS-850AM M12II 850W Evo Edition 80 Plus Bronze Fully Modular Power Supply

- Seasonic M12II Modular Power Supply
- 850W 80 Plus Bronze Certified
- Smart & Silent Fan Control [S2FC]
- 12cm Ball Bearing Cooling Fan
- Soft-Mount Rubber Cushions
- Multi-GPU Technologies Supported
- Universal Ventilation [Honeycomb Structure]
- Detachable Modular Cables

Introduction:
Seasonic M12II Bronze Series has been the ever-popular power supply series of the semi modular category. Now Seasonic extends the semi-modular series by introducing M12II Bronze 650/750/850 to provide consumers a larger selection in the entry level 80PLUS Bronze certified category.
The M12II Bronze new models have built in a full protection feature including OCP, OPP,OTP, OVP, SCP & UVP and meet worldwide safety and environmental standards. The all-new M12II-650/750/850 units are the new leaders in the 80 PLUS Bronze category andanother great addition to the Seasonic Retail power supply family.

Specifications:
Type     ATX12V / EPS12V
Maximum Power     850W
Fans     1
PFC     Active
Main Connector     20+4Pin
+12V Rails     Single
PCI-Express Connector     4 x 6+2-Pin
SATA Power Connector     8

Connectors:
1 x 20 / 24P Main Power
1 x EPS12V / ATX12V (8P / 4P)
1 x EPS 12V (8P)
4 x PCI-E (6P / 8P)
8 x SATA
5 x Peripheral (4P)
2 X FDD (4P)

Features:
DC to DC Converter Design
High Reliable 105? Japanese Brand Capacitors
Ample +12V Outputs
Active Power Factor Correction [99% PF Typical]
Smart & Silent Fan Control [S2FC]
12cm Ball Bearing Cooling Fan
Soft-Mount Rubber Cushions
Multi-GPU Technologies Supported
Detachable Modular Cables
Easy Swap Connectors
Universal Ventilation [Honeycomb Structure]
