Specification:
CPU: Dual-core ARM Cortex M0+ processor with flexible clock running up to 133 MHz
Storage: 264KB of SRAM and 2MB of on-board Flash memory
I/O Pins: 11 digital pins, 4 analog pins, and 11 PWM pins
Interface: 1 I2C interface, 1 UART interface, 1 SPI interface, and 1 SWD Bonding pad interface
Power Supply and Downloading Interface: USB Type-C interface
LEDs: 1 user LED, 1 power LED, two LEDs for serial port downloading, and 1 RGB LED
Buttons: 1 RESET button and 1 BOOT button
Power Pads: For battery power supply
Software Compatibility: Supports MicroPython, for Arduino, and CircuitPython
Projection Cover: Provides protection for the circuit
Dimensions: 20x17.5x3.5 mm
Features:
1. Powerful Performance: The XIAO RP2040 features a dual-core ARM Cortex M0+ processor r
