Package weight: 0.15 kgFunctions:
1.Over-voltage protection
2.Under-voltage protection
3.Over-current protection
4.Automatic recovery
5.Voltage display(voltage measurement)
6.Current display (current measurement)
7.KWH display (kwh measurement)
8.Temporary KWH can be reset
9.Fauly inquiry
10.Cycle countdown timer
Product Parameters:
1.Model number:SVP-977
2.Power supply:230VAC 50/60Hz
3.Max.Loading power:1~63A Adjustabledefault:63A
4.Over-voltage protection value range:221V~300 (default:280V)
Over-voltage recovery voltage range:220V~299V(default:250V)
Over-voltage protection action time:0.1s~10s(default value:0.1s)
5.Under-voltage protection value range:219V~150V (default:160V)
Under-voltage recovery voltage range:151V~220V (default:180V)
Under-voltage protection action time:0.1s~10s(default:0.1s)
6.Over-current adjustment range:1~63A default:63A
Over-current action range:0.1~512 second default:5.0s
7.Recovery delay time:2s~600s(default:60s)
8.Power-on delay time:2s~255s(default:2s)
9.Power consumption : <2W
10.Electric machinery life : 100,000 times
11.Installation:35mm DIN rail
Package included:
1 x Voltage and Current Protector
