Power Specifications:
- Power Supply: (Bar) AC110-240V,50/60Hz
: (Subwoofer) AC110-240V, 50/60Hz
- Power Consumption: (Bar) 72W
: (Subwoofer) 64W
Speaker Specifications
- Driver Unit: 58x90x3+6.5"
- Input Impedance: 8 x3+3
- Frequency Response: 45Hz-20KHz
- Signal-to-Noise Ratio: 72dB
- Input Sensitivity: SB: 800mV 50mV
SW: 800mV 50mV
Dimensions & Weight
- Soundbar Dimension (mm): 960(L) x 106.5(W) x 70(H)
- Subwoofer Dimension (mm): 190(L) x 306(W) x 367(H)
- Box Gross Dimension (mm): 1011(L) x 247(W) x 451(H)
- Weight (Net) (kg): 6.81
- Weight (Gross) (kg): 8.5
Blue Tooth connection procedure:Ensure sound bar is on. Press the pair button on the remote control. BT Ready will appear on your soundbar. On your Skyworth TV select settings. Go to all settings. Select Sound and Sound output. Select Blue tooth speaker list. Search for sound bar. Pair and connect.
What's in the box
1 x Remote Control
1 x Aux cable
1 x Wall Mounting Kits: 1 Set
