This Smart Wi-Fi Ambient Air Temperature Monitor and Switch 16A 3Kw. Includes energy/power consumption monitor and remote control 433Mhz feature.Smart Switch any device ON or OFF based on the high/low-temperature readings. Perfect for Grow Tents and any environment where full automated control is required.Based on either of the two readings you can automate certain functions like switching ON and OFF such as Fans, Irrigation mist sprinkler systems when values go above or below certain pre-defined values. Optional: you can also have an additional manual control via a 433Mhz remote control.
Simply, 'Wire, Configure and Play'.
- Other Temperature / Humidity products you may require:
- Smart Humidity Monitor + 16A Switch + 433Mhz remote control option [click here]
- Smart Ambient Air Temperature Monitor + 16A Switch + 433Mhz remote control option [click here] - this product
- Smart Water Temperature Monitor + 16A Switch + 433Mhz remote control option [click here]
Typical Applications:
- Monitor humidity and automate certain ON/OFF actions such as extractor fans, mist irrigation, etc.
Home Automation made Smart, Simple, and Affordable via the Tuya, Smart Life App (Android or IOS), offering the fastest, most stable platform and widest range of Smart Products. Supports Alexa, Google Home, and IFTTT.
Great way to make any appliance or device, 'Smart'.
Typical Applications & Uses
Suitable for farms, small holdings, larger homes, or any area where your Wi-Fi range is limited. irrigation, gate or access control, and alarm systems. The switch can be connected to a contactor switch relay (we stock 25A single and 3-phase) to switch even larger currents or even 3-phase pumps etc.
- Mounting the switch in a plastic waterproof housing [click here] is preferred. (a steel cabinet for example will reduce the range)
- Your standard garage door and gate remotes are 'rolling code' remotes and are NOT compatible with this switch.
Home Automation made Smart, Simple, and Affordable via the Tuya, Smart Life App (Android or IOS), offering the fastest, most stable platform and widest range of Smart Products. Supports Alexa, Google Home, and IFTTT.
'HOW TO' WIFI SMART YOUTUBE VIDEO [click here] - connect to your cell phone
Product Features
- Small and Compact design - high current. Wire, Configure, and Play.
- Activation dates, days of the week, start time and duration can all be pre-configured via the Smart Life application giving you complete remote control and ON/Off overwrite.
- Supports Voice Commands and AI units such as Amazon Alexa Echo and Google Home solutions.
- All your Smart Devices are connected via a Single stable Platform been the Smart Life app from Tuya.
- The entire Smart Life system performance relies on an 'adequate WIFI' (2.4GHz only) signal. We recommend the use of our range of WIFI Extender products [click here]
Enclosures / Housing
- Need an Enclosure, Housing, or Junction Box for this switch
- Note: Only enclosures marked 'medium' are suitable for use with this switch [click here]
- If required, remove the PCB from the outer casing of the switch for a smaller footprint
Specifications
- Electrical Input Voltage: 85-250V AC
- Switch Power Rating: 20A max, 4400W
- Ambient Air Temperature Range: -20ºC to +70ºC
- Display Resolution: 0.1ºC increments.
- Product dimensions：96 x 45 x 31mm
- Material: White ABS (Fire-retardant)
- Wireless Frequency: 802.11 b/g/n 2.4GHz, WPA-PSK/WPA2-PSK
How to pair a 433Mhz Remote Control
- Press and hold the button on the switch till the lights flash blue (+/-3 seconds)
- Now press the required button on the remote - the unit should now be paired.
What is in the Box?
1x Smart Humidity Switch 16A
1x Instruction Manual
