SN74LS02N QUAD 2-INPUT NOT GATE DIP-14

If you are working on a digital gate level project to do custom processing, this NOR gate is an absolute must to include in your project since these gates already include an inverter gates and an OR gate, which means that the complexity of your circuit can be reduced quite a lot. If you do not have one of these gates with you, you can always build it by making use of an OR gate and an inverter gate. The basic function of this gate is to invert the output of an OR gate, so that it only give a logic high output when both of the inputs of the gate is set to a low level logic.

Technical specifications:

Pin layout:

Extra resources:

Datasheet for SN74LS02
