Solar Inverter - 6.2kW 7kVA High Voltage, 48V, DUAL AC OUTPUTS, Pure Sine wave Inverter, Stand a...

6.2kW / 7kVA 48V High Voltage Hybrid Off-Grid Inverter Pure Sine Wave, Dual Output, RGB Status LEDs, Non-Parallelable / Non-Expandable

User manual available here

IP Rating:

• IP21
• Not recommended for installation location with high humidity.
• If the inverter needs to be installed close to the ocean please make use of a dehumidifier.

Features:

• Programmable supply priority for PV, Battery or Grid.
• Stand alone unit, CANNOT be connected in parallel.

• Cold start function.
• DUAL AC outputs. (MAIN & 2ND)

Max Watt Output:

• Continuous: 7kVA / 6.2kW
• Surge: (5 seconds) : 12.4kW

Output and Charging Source Settings:

• Solar-Utility-Battery & Solar-Battery-Utility.

• Solar only: 110A (maximum).
• Grid only: up to 100A.

Solar input specifications:

• 22A max PV input.
• PV Panels range : 60Vdc - 500Vdc
• PV Panels maximum: 6 500W
• PV Panels connection : series only.

• No Load Power Consumption: 50W

Monitoring & Setting :

• LCD screen.

Expansion: More Inverters

• Can ONLY be used as single inverter.

 Physical dimensions

• 500 x 415 x 205mm (Boxed)
• 10KG

What's in the box

• Inverter
• User manual

IMPORTANT: THE CORRECT SETTINGS ON THE INVERTER WILL AID IN ENSURING OPTIMAL BATTERY LIFE.

Warranty:

12 Months Warranty

Please take note of the full warranty terms and conditions.
