Solar Inverter - 6.2kW 7kVA High Voltage, 48V, DUAL AC OUTPUTS, Pure Sine wave Inverter, Stand a...

6.2kW High Voltage, 48V, RGB Status LED's, Pure Sine wave Inverter, Stand alone ONLY (cannot parallel connect to another inverter)

IP Rating:

• IP21
• Not recommended for installation location with high humidity.
• If the inverter needs to be installed close to the ocean please make use of a dehumidifier.

Features:

• Programmable supply priority for PV, Battery or Grid.
• Stand alone unit, CANNOT be connected in parallel.

• Cold start function.
• DUAL AC outputs. (MAIN & 2ND)

Max Watt Output:

• Continuous: 7kVA / 6.2kW
• Surge: (5 seconds) : 12.4kW

Output and Charging Source Settings:

• Solar-Utility-Battery & Solar-Battery-Utility.

• Solar only: 110A (maximum).
• Grid only: up to 100A.

Solar input specifications:

• 22A max PV input.
• PV Panels range : 60Vdc - 500Vdc
• PV Panels maximum: 6 500W
• PV Panels connection : series only.

• No Load Power Consumption: 50W

Monitoring & Setting :

• LCD screen.

Expansion: More Inverters

• Can ONLY be used as single inverter.

 Physical dimensions

• 500 x 415 x 205mm (Boxed)
• 10KG

What's in the box

• Inverter
• User manual

IMPORTANT: THE CORRECT SETTINGS ON THE INVERTER WILL AID IN ENSURING OPTIMAL BATTERY LIFE.

Warranty:

12 Months Warranty

Please take note of the full warranty terms and conditions.

**FREE DELIVERY NATIONWIDE!!!**

Free nationwide delivery on inverters.

PLEASE NOTE : transport costs of warranty claims to The Sun Pays' Rayton office will be at the cost of the customer.
