Key Features
Mechanical Data |
Item | Specification |
Cell Type | 156.75x156.75mm Poly-crystal |
Cell Orientation | 72 (6x12) |
Module Dimensions | 1957x992x40mm |
Weight | 23.0 kg / 50.71 lbs |
Front Cover | 3.2mm high transmittance, reinforced glass |
Back Sheet | Anti-aging film |
Frame Material | Anodized aluminum alloy |
Junction Box | IP 68 , 3 diodes |
Cable | 4.0mm2 |
Connector | MC4 compatible connector |
Electrical Data |
Item | Specification |
Maximum Rating Power (Pmax) | 440 |
Module Efficiency | 20.24 |
Open Circuit Voltage (Voc) | 49.47 |
Maximum Power Voltage | 41.16 |
Short Circuit Current (Isc) | 11.16 |
Maximum Power Current | 10.69 |
Operating Conditions |
|
