Please note: This inverter requires 2 x 12V batteries or a single 24V Lithium battery (Sold separately)
Hybrid Solar Inverter
Features:
- Pure sine wave solar inverter
- Configurable input voltage range for home appliances and personal computers via LCD setting
- Configurable battery charging current based on applications via LCD setting
- Configurable AC/Solar Charger priority via LCD setting
- Compatible to mains voltage or generator power
- Auto restart while AC is recovering
- Overload / Over temperature / short circuit protection
- Smart battery charger design for optimize battery performance
- Cold function start
- WIFI available for IOS and android
- Built-In 80A MPPT solar charge
- Built-In anti-dusk kit for the harsh environment(optional)
- Compatible with lithium-ion battery
- High PV input voltage range (90V~450VDC)
- Intelligent fan speed adjustment
Additional Specifications:
- Model: 3.2KVA /24V
- DC Input: 24VDC
- AC Input: 230VAC, 50Hz, 21.3A Max
- AC Output: 230VAC, 50Hz, 3000W
- Wire Size: 1 x 6AWG
- Cable: 14mm
- Torque value(max): 2Nm
- Rated Power: 3200VA/3000W
Specifications:
Input:
- Voltage: 230VAC
- Selectable Voltage Range: 170 -280V AC (For Personal Computers): 90 -280V AC| (For Home Appliances)
- Frequency Range: 50Hz / 60Hz (Auto-sensing)
Output:
- AC Voltage Regulation (Battery Mode): 230V AC 5%
- Surge Power: 6400VA
- Transfer Time 10 ms (For Personal Computers); 20 ms (For Home Appliances)
- Waveform Pure sine wave
Battery:
- Battery Voltage 24VDC
- Floating Charge Voltage: 27VDC
- Overcharge Protection: 31VDC
Solar Charger & AC Charger:
Maximum PV Array Open Circuit Voltage 450V DC
Maximum PV Array Power: 3000W
Maximum Charging Current: 80A
Maximum Efficiency: 98%
Physical
Dimension (D x W x H): 348 x 282 x 105mm
Net Weight: 5.5kgs
Communication Interface: RS232(Standard) WIFI(Optional)
What's in the box
1 x SolarFirst -3KVA 24v Pure Sine Hybrid Inverter - 80A MPPT
