Input (DC)
Maximum PV Array Input Power: 10000Wp
Maximum PV Input Voltage: 600V
Nominal DC Operating Voltage: 360V
Maximum Input Current: 14A / 14A
Maximum Short Circuit Current: 16A / 16A
MPPT Voltage Range: 70V 550V
Start Operating Voltage: 60V
Number of MPP Trackers: 2
Strings per MPP Tracker: 1/1
AC Input & Output
Nominal AC Output Power: 7500W
Nominal AC Output Current: 32.6A
Maximum AC Output Apparent Power: 7500VA
Maximum AC Output Current: 32.6A
Maximum AC Input Apparent Power: 9200VA
Maximum AC Input Current: 40A
Nominal AC Voltage: 220V/230V/240V
Nominal Grid Frequency Range: 50Hz/60Hz
Displacement Power Factor: 0.8 leading ~ 0.8 lagging
THDi, rated power: <2%
Environment Limit
Ingress Protection: IP65
Operating Temperature Range: -35C to +60C (derating at 45C)
Maximum Operation Altitude: <3000m
Humidity: 0% to 100% (Non Condensing)
Storage Temperature: -40C to +70C
Communication: CT/Meter/External Control RS485/Pocket Series/DRM/USB Upgrade
Certification: IEC62109-1 / IEC62109-2 / AS4777
