Sonoff S-Mate
The Sonoff S-MATE is a battery-powered remote that does not require a neutral wire in the mounting box.
S-MATE can connect to ordinary 1/2/3-button wall switches, serving as a remote controller.
One MINIR4 can connect to multiple S-MATEs, and one S-MATE can be added to three MINIR4s.
After pairing with the MINI R4, the S-MATE can locally control the MINI R4 through the "eWeLink-Remote" signal and thus trigger other smart devices in the smart scene.
The S-MATE is suitable for almost any switch type, such as pulse switch or rocker switch, and can change your existing switch into a smart one.
The Sonoff S-MATE is the module that can transmit the "eWeLink-Remote" signal. We also name it "eWeLink-Remote sub-devices". MINI R4 is the device that receives the "eWeLink-Remote", and we name it "eWeLink-Remote gateway".
Once S-MATE was added to any eWeLink-Remote gateway( such as MINI R4, M5), can not only control all products with eWeLink-Remote gateway when there is no network connection locally but also controls any other Sonoff smart device in the smart scene when there is a network connection. It is "eWeLink-Remote" Control, you can click this post to learn more.
Features
- "eWeLink-Remote" Control - Use it with the MINI R4 or other smart switch with the gateway function of "eWeLink-Remote", it can achieve "eWeLink-Remote" control.
- Control Ways - Control built-in "eWeLink-Remote gateway" devices when no Internet is available and it can trigger other smart devices in the smart scene when there is a network connection.
- Compatible With Switch Types - S-MATE is fit for almost any switch type, like, pulse switch, rocker switch, change your existing switch into a smart one.
- Switch Mate - Works with MINI R4 smart switch, M5 smart wall switch and S40/S40 LITE smart plug.
LoA and Icasa approved.
Back To Shop
Specifications
- Input: 100-240V~50/60Hz 16A Max
- Output: 100-240V~50/60Hz 16A Max
- Battery model: CR2032
- Dimension: 51×44.5x24mm
- Shell material: PC V0
- "eWeLink Remote" working distance: Up to 50M in Open Space
- Work temperature: -10°C~40°C
