CPU x86-64-AMD Ryzen Zen 2
8 Cores / 16 Threads
Variable frequency, up to 3.5 GHz
GPU AMD Radeon RDNA 2-based graphics engine
Ray Tracing Acceleration
Variable frequency, up to 2.23 GHz (10.3 TFLOPS)
System Memory GDDR6 16GB
448GB/s Bandwidth
SSD 825GB
5.5GB/s Read Bandwidth (Raw)
Optical Drive Ultra HD Blu-ray (66G/100G) ~10xCAV
BD-ROM (25G/50G) ~8xCAV
BD-R/RE (25G/50G) ~8xCAV
DVD ~3.2xCLV
PS5 Game Disc Ultra HD Blu-ray, up to 100GB/disc
Video Out HDMI OUT port
Support of 4K 120Hz TVs, 8K TVs, VRR (specified by HDMI ver.2.1)
Audio Tempest 3D AudioTech
Dimensions PS5: Approx. 390mm x 104mm x 260mm (width x height x depth)
(excludes largest projection, excludes Base)
PS5 Digital Edition: Approx. 390mm x 92mm x 260mm (width x height x depth)
(excludes largest projection, excludes Base)
Weight PS5: 4.5kg
PS5 Digital Edition: 3.9kg
Power PS5: 350W
PS5 Digital Edition: 340W
Input/Output USB Type-A port (Hi-Speed USB)
USB Type-A port (Super-Speed USB 10Gbps) x2
USB Type-C® port (Super-Speed USB 10Gbps)
Networking Ethernet (10BASE-T, 100BASE-TX, 1000BASE-T)
IEEE 802.11 a/b/g/n/ac/ax
Bluetooth® 5.1
DualSense Wireless Controller Specifications
Dimensions Approx. 160mm x 66mm x 106mm (excludes largest projection) (width x height x depth)
Weight Approx. 280g
Buttons PS button, Create button, Options button,
Directional buttons (Up/Down/Left/Right), Action buttons (Triangle, Circle, Cross, Square),
R1/L1 button,
R2/L2 button (with Trigger Effect)
Left stick / L3 button, Right stick / R3 button, Touch Pad button, MUTE button
Touch Pad 2 Point Touch Pad, Capacitive Type, Click Mechanism
Motion Sensor Six-axis motion sensing system (three-axis gyroscope + three-axis accelerometer)
Audio Built-in Microphone Array, Built-in Mono Speaker, Stereo Headset Jack
Output : 48kHz/16bit, Input : 24kHz/16bit
Feedback Trigger Effect (on R2/L2 button), Vibration (haptic feedback by dual actuators), Indicators (Light bar / Player indicator / MUTE status)
Ports USB Type-C® port (Hi-Speed USB), Stereo Headset Jack, Charging Terminals
Communication Wireless Bluetooth® Ver5.1
Wired USB connection (HID, Audio)
Battery Type Built-in rechargeable lithium-ion battery
Voltage DC 3.65V
Capacity 1,560mAh
