Power Source: 14.4 Volts DC Negative Ground
Input Current: 0.5 Amp Max
Performance Metrics:
Distortion: 0.01% THD at 1V Output Level
Frequency Response: 10Hz 30kHz (-3dB)
Signal to Noise Ratio (S/N): >95dB (A-weighted)
Channel Separation: 60dB
Crossover Settings:
Front Highpass (X1): 32-400Hz
Front Highpass (X20): 640-8kHz
Rear High-pass (3-way only): 32-400Hz
Subwoofer: 32-400Hz
Crossover Slope Rate:
Low Pass: 18dB per octave (3rd order Butterworth)
High-pass: 12dB per octave (3rd order Butterworth)
Subwoofer Boost:
Range: 0dB to 12dB (variable) at 45Hz
Input & Output Impedance:
Input Impedance: 20k Ohms
Output Impedance: 100 Ohms
Output Metrics:
Output Gain: 1:2 (+6Db)
Output Voltage Level: 5 Volts Max
Dimensions:
Width: 5.5
Length: 7.5
Height: 1.75
