Stmicroelectronics (STKNXTR) Transceiver KNX Certified, 9.6 Kbaud

Transceiver KNX Certified, 9.6 Kbaud, 20V to 32V Supply, 30mA, VFQFPN-24Product OverviewMiniature KNX transceiver with voltage regulators and microcontroller support.This STKNX is a transceiver device for KNX TP communication. The small packageand few external components enable the very compact KNX nodes design. The simpleinterface to the µC allows easy replacement of physical layer discretecomponents implementations. Typically used in KNX twisted pair network (KNXTP1-256).KNX certified, KNX TP1-256 supportedEasy interface to µCVery small system solutionTwo integrated voltage regulators for external use in applicationKNX bus power extractor supporting bus current up to 30mAAdjustable KNX bus current slew rate dI/dtNo crystal requiredProduct InformationData Rate: 9.6KbaudSupply Voltage Min: 20VSupply Voltage Max: 32VController IC Case Style: VFQFPNNo. of Pins: 24PinsOperating Temperature Min: -40°COperating Temperature Max: 85°CMSL: MSL 3 - 168 hours
