ARM MCU, USB Line, STM32 Family STM32F0 Series Microcontrollers, ARM Cortex-M0,32 bit, 48 MHzProduct OverviewThe STM32F072RBT6 is a Microcontroller incorporates the high-performance ARMCortex®-M0 32-bit RISC core operating at a 48MHz frequency, high-speed embeddedmemories (up to 128kb of flash memory and 16kb of SRAM) and an extensive rangeof enhanced peripherals and I/Os. All devices offer standard communicationinterfaces (two I²Cs, two SPIs/one I2S, one HDMI CEC and four USARTs), one USBFull speed device (crystal-less), one CAN, one 12-bit ADC, one 12-bit DAC withtwo channels, seven general-purpose 16-bit timers, a 32-bit timer and anadvanced-control PWM timer. A comprehensive set of power-saving modes allows thedesign of low-power applications.ARM 32-bit Cortex-M0 CPU, Frequency up to 48MHz Core64 to 128kb Flash Memory16kb SRAM with HW ParityCRC Calculation UnitVDDA = VDD to 3.6V Analogue SupplyPower-on/Power Down Reset (POR/PDR)Sleep, Stop and Standby Low Power Modes4 to 32MHz Crystal Oscillator32kHz Oscillator for RTC with CalibrationInternal 8MHz RC with x6 PLL OptionInternal 48MHz Oscillator with Automatic Trimming Based on ExternalSynchronizationAll Mappable on External Interrupt VectorsUp to 68 I/Os with 5V Tolerant Capability and 19 with Independent Supply VDDIO27-channel DMA ControllerOne 12-bit, 1.0µs ADC (up to 16 Channels)0 to 3.6V Conversion RangeCalendar RTC with Alarm and Periodic Wakeup from Stop/StandbyOne 16-bit Advanced-control Timer for 6-channel PWM Output32-bit and Seven 16-bit Timers, with up to 4 IC/OC OCN usable for IR controldecoding or DAC controlIndependent and System Watchdog TimersApplicationsEmbedded Design & Development, Signal Processing, Computers & ComputerPeripheralsProduct InformationProduct Range: STM32 Family STM32F0 Series MicrocontrollersNo. of Bits: 32bitData Bus Width: 32bitOperating Frequency Max: 48MHzProgram Memory Size: 128KBRAM Memory Size: 16KBIC Case / Package: LQFPNo. of Pins: 64PinsMCU Case Style: LQFPNo. of I/O's: 51I/O'sInterfaces: CAN, I2C, SPI, USART, USBEmbedded Interface Type: CAN, I2C, SPI, USART, USBSupply Voltage Min: 2VSupply Voltage Max: 3.6VMCU Family: STM32MCU Series: STM32F0MSL: MSL 3 - 168 hours
