Hybrid Inverter 2KVA 1600 Watt MPPT 12V Sun Solar
This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Features
Pure sine wave inverter
Configurable input voltage range for home appliances and personal computers via LCD setting
Configurable battery charging current based on applications via LCD setting
Configurable AC/Solar Charger priority via LCD setting
Compatible to mains voltage or generator power
Auto restart while AC is recovering
Overload/ Over temperature/ short circuit protection
Smart battery charger design for optimized battery performance
Cold start function
WIFI/GPRS (Optional)
Can connect to lithium battery
3.2 Basic System Architecture
The following illustration shows basic application for this inverter/charger. It also includes following devices to have a complete running system:
Generator or Utility.
PV modules
L x 390mm H x 100mm W x 290mm
(PLEASE NOTE THE FANS ARE ALWAYS ON)
What's in the box
1 x Hybrid Solar Inverter
1 x Manual
Battery Specifications:
Longer Cycle LifeOffers up to 10 times longer cycle life and five times longer float/calendar life than lead acid battery, helping ti minimize replacement cost and reduce total cost of ownership. Lighter WeightAbout 40% of the weight of a comparable lead acid battery. A'drop in' replacement for lead acid batteries. Higher PowerDelivers twice power of lead acid battery, even high discharge rate, while maintaining high energy capacity. Wider Temperature Range-20~60 Superior SafetyLithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overchaeging or short circuit situation.
- Built In Protection -Over-Charge, Over-Discharge, Over-Temperature
Nominal Voltage : 12.8V
Nominal Capacity : 100Ah
Nominal Energy : 1280Wh
Combination Method : 4S
Cycle Life : 5000 cycles @50%DOD @35
Months Self Discharge : Months Self Discharge
Efficiency of Charge : 97%
Recommended Charging Voltage : 14.2V
Recommended Charging Current : 50A
Recommended Discharging Current ; 50A
Dimensions ( in. /mm. ) 329*173*217mm
Weight ( lbs. /kg. 11kg
