Sunix 4 ports RS-232 High Speed Express Card

Description

- 4 port RS-232 High Speed ExpressCard

- Controller: SUNIX Matrix UL7512EQ (16C650 UART Compatible)

- Bus Interface: PCI Express one lane (x1)

- ExpressCard Type: 34mm

- PCB connector: DB44 Female

Serial Communication

- Interface: RS-232

- No. of Port: 4-port

- FIFO: 32 byte (Hardware)

- Signal: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, RI

- Baud rate: 50 bps to 921.6 Kbps

- Data bit: 5,6,7,8

- Stop bit: 1,1.5,2

- Parity: None, Even, Odd, Space, Mark

- Flow Control: RTS/CTS (Hardware) , XON/XOFF(Software)

- Protection: ±15KV Human Body Model (HBM), ±15KV IEC1000-4-2 Air Gap Discharge, ±8KV IEC1000-4-2 Contact Discharge

Regulatory Approvals

- Hardware: CE, FCC, VCCI, BSMI

- Software: Microsoft WHQL Window XP

Environment

- Operating Temperature: 0 to 60 °C (32 to 140 °F)

- Operating Humidity: 5% to 95% RH

- Storage Temperature: -20 to 85 °C (-4 to 185 °F)

Connection Cable

- Cable: DB44 male to 4-port DB9/ DB25 Male 40cm cable

Dimension(Unit = mm)

- Iron Case: 80(W) x 34(D) x 5(H)

- Plastic Case: 39(W) x 64(D) x 20(H)
