Description | |
Product Description | 2-port RS-232 High Speed Universal PCI Low Profile Serial Board with Power Output |
Serial Communication | |
Interface | RS-232 |
Controller | SUNIX SUN1989 (16C950 UART Compatible) |
Bus | Universal PCI 64/32bit 3.3V/5V PCI Ver 3.0, 2.3, 2.2, 2.1 |
No. of Port | 2-port |
IRQ & IO | Assigned by System |
FIFO | 128 byte (Hardware) |
Signal | TxD, RxD, RTS, CTS, DTR, DSR, GND, 5V/12V/ DCD, 5V/12V/RI |
Baud rate | 50 bps to 921.6 Kbps |
Data bit | 5,6,7,8 |
Stop bit | 1,1.5,2 |
Parity | None, Even, Odd, Space, Mark |
Flow Control | None, Xon/Xoff, RTS/CTS |
Protection | ±15KV ESD protection for each signal Human Body Model (HBM) ±15KV IEC1000-4-2 Air Gap Discharge ±8KV IEC1000-4-2 Contact Discharge |
PCB connector | DB44 Female |
Driver Support | |
Windows Client | XP / Vista / 7 / 8.x / 10 (X86/X64) / 11 |
Windows Server | 2003 / 2008 / 2012 / 2016 / 2019 / 2022 (X64) |
Windows Embedded | XP Embedded / POSReady 2009 / POSReady / Embedded System 2009 |
Linux | Linux 2.x / 3.x / 4.x / 5.x |
DOS | DOS |
