DOWNLOAD SPECIFICATIONS HERE
| Rated AC Output and UPS Power | 12000W |
| Max. AC Power | 13200W |
| Peak Power (off-grid) | 2 times of rated power, 10 S |
| AC Output Rated Current | 17.4A |
| Max AC Output Current | 19.1A |
| Max Continuous AC Passthrough | 60A |
| Output Frequency and Voltage | 50-60Hz; 230/400Vac (Three Phase) |
| Grid Type | Three Phase |
| Current Harmonic Distortion | THD<3% (Linear load<1.5%) |
| Max. DC Input Power | 15000W |
| PV Input Voltage | 450V (140V~1000V) |
| MPPT Range | 140V~800V |
| Start-up Voltage | 160V |
| PV Input Current | 25A+12.5A |
| No. of MPPT Trackers | 2 |
| No. of Strings Per MPPT Tracker | 2+1 |
| Max. Efficiency | 97.6% |
| MPPT Efficiency | 97.0% |
| Euro Efficiency | 99.9% |
| Battery Type | Lead-acid or Lithium-ion |
| Battery Voltage Range | 40~60V |
| Max. Charging Current | 240A |
| Max. Discharging Current | 240A |
| Charging Curve | 3 Stages/Equalization |
| External Temperature Sensor | Optional |
| Charging Strategy for Li-Ion Battery | Self-adaption to BMS |
| Operating Temperature Range | -25~60°C, >45°C Derating |
| Cooling | Fan |
| Noise | <30dB |
| Communication with BMS | RS485; CAN |
| Weight | 45 kg |
| Dimensions (LxWxH) | 673 x 462 x 265 mm |
| Protection Degree | IP65 |
| Installation Style | Wall-mounted |
| Warranty | 5 years |
| Grid Regulation | UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98,G99, IEC61683, IEC62116, IEC61727 |
| Safety Regulation | IEC2109-1, IEC62109-2 |
| EMC | EN61000-6-1, EN61000-6-3, FCC 15 Class B |
