Switchcraft (EN3P6M-F) Circular Connector, Receptacle, 6 Contacts

Circular Connector, EN3 Series, Panel Mount Receptacle, 6 Contacts, Solder Pin,BayonetProduct OverviewThe EN3 series Mini Weathertight Connector has gold-plated copper alloycontacts. The O-ring is moulded onto cord housing assembly and gasket is mouldedonto panel housing assembly to prevent leakage and eliminate need for additionalO-rings and gaskets. The cable clamp assembly features living hinges, which snapeasily onto and support the cable. The thermoplastic rubber body simulatesclosed entry contact system to prevent probe damage or accidental loss of springretention due to misaligned or bent pins. The panel connector shell features apositioning keyway to prevent misalignments and a polarizing single D design forproper panel mounting and to prevent rotational movement. It exceeds enclosurerating IP16/IP18 when not mated or covered and IP66/IP68 when mated or covered(IEC 529). * Superior leakage protection * Integral O-ring and gasket * Reduced part count for reduced labour to assemble * Abrasion-resistant thermoplastic boot provides strain relief * Optional cap covers panel housing assembly when not in use * Exceeds enclosure rating 6P at 1000V when mated or covered (NEMA 250) * 600VRMS at sea level Voltage rating * 100MR at 77°F Insulation resistance * 5mR Minimum contact resistanceApplicationsAutomation & Process Control, Logistics, Medical, Sensing & InstrumentationProduct Information- Product Range: EN3 Series- Circular Connector Shell Style: Panel Mount Receptacle- No. of Contacts: 6Contacts- Circular Contact Type: Solder Pin- Coupling Style: Bayonet- Connector Body Material: Thermoplastic, Glass Filled Body- Contact Material: Copper Alloy- Contact Plating: Gold
