Features & Benefits: 2400W Inverter for Power Outages
- Powerful 3000VA 2400W Performance
- Versatile Voltage Capacity
- Selectable Voltage Range
- Energy Efficient
- Ultra-Fast Transfer Time
- Efficient Charging
- Bypass Mode
- Saver Mode
- Input & Output Protection
Specifications:
Capacity(VA) 3000VA
Rated Power 2400W
Voltage(DC) 24V
Input Voltage 220VAC
Voltage Range 154-265VAC ;185-264VAC ( selectable)
Frequency 50-60HZ Auto sensing
Power Factor 0.8
Output Voltage 220VAC 10%
Frequency 50/60Hz 5%
Waveform Pure Sine Wave
Transfer Time (AC to DC) <8ms
Transfer Time (DC to AC) <8ms
Output Voltage Regulation 10%
Bypass Mode Yes
Saver Mode Yes
Efficiency >98%
Input/Output Protection Circuit Breaker
Battery Type VRLA / GEL /GEL DEEP CYCLE/Lithium
Charging Current 30A/15A
Battery Charging Voltage 13.5VDC/27VDC/54VDC
Maximum PV Array Power 800W/1600W/3200W
MPPT(PWM) Input Voltage Range 24V: MPPT 30V-150VDC / PWM 30V-60VDC
48V: MPPT 60V-150VDC / PWM 60V-105VDC
Maximum solar charge current 60A
Size LxWxH(mm) 470mm x 335mm x 210mm
Weight (kg) 20
