Synology DiskStation DS1522+ AMD Ryzen R1600 5-bay NAS
Flexible Data Management Platform for Homes and SOHO
The Synology DS1522+ is a versatile 5-bay NAS solution that is easy to scale and expand as your needs change, with optional support for up to 15 drives, fast networking, and NVMe SSD caching. Powered by Synology DiskStation Manager (DSM), it offers a flexible all-in-one solution for data sharing, synchronization, backup, and surveillance.
Versatile Storage for Any Purpose
The DS1522+ comes out of the box with intuitive and comprehensive file management, media organization, and backup options, making it ideal for IT enthusiasts, creative professionals, and business owners looking for a powerful and compact storage system.
- Up to 736 MB/s sequential read and 796 MB/s sequential write performance enables fast file sharing, syncing, streaming, and backup for multiple users.
- Supports 5 x SATA HDD/SSD 2.5" and 3.5" drives,6 expandable to 15 drives with two Synology DX517 expansion units.
- Up to 32 GB DDR4 ECC memory for protection against potential crashes and inadvertent changes in data through automatic correction of data errors.
- Accommodate multiple streams or transfer tasks with four Gigabit RJ-45 ports, which can be bonded using Link Aggregation to provide automatic network failover and load balancing.
- Maximize return on investment by upgrading your storage platform as more demanding needs arise with two built-in M.2 NVMe SSD cache slots and an optional 10GbE RJ-45 Network Upgrade Module.
Technical Specification
Product: Synology DiskStation DS1522+
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: Serial ATA II, Serial ATA III
Storage drive sizes supported: 5x 2.5-inch or 3.5-inch, 2x M.2
Processor manufacturer: AMD
Processor family: AMD Embedded R-Series SoC
Processor model: R1600
Internal memory: 8 GB ECC SODIMM
Internal memory type: DDR4
Maximum RAM supported: 32 GB
LAN ports: 4 x 1GbE RJ-45
Ethernet LAN data rates: 10,100,1000 Mbit/s
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Network expansion Supports: E10G22-T1-Mini 10GbE RJ-45 Network Upgrade Module
Chassis type: Desktop
Cooling type: Active
Product colour: Black
Weight: 2.7 kg
